Modulo Pallet spike
A low ceiling in the production area, but still be able to unload big bags on a frame? The solution is the Modulo Pallet spike. By placing the big bag first on a pallet, and only then on the frame, the forklift truck does not have to place the bigbags on the loops on the frame. The height of the ceiling is therefore no longer a limiting factor!
Unloading small quantities from the bigbag with ease, with the Modulo Pallet spike you can easily create a bigbag unloading station! The Modulo Pallet consists of a powder-coated steel frame with a steel pallet. With this frame, bigbags can be unloaded without a discharge hose.
The Modulo Pallet spike is easy to use: By lowering the bigbag onto the spike, it cuts open the bigbag. The bigbag remains on the bottom plate.
With one action, you're done! Thanks to the fixed dosing valve, dosing can be done very accurately, because it closes seamlessly. With a load capacity of 2000kg, this frame can handle any bigbag without any problem.
Suitable for all "rolling" products such as animal feed, fertilizer and seeds. But also gravel, sand and, for example, coffee. The Modulo Pallet spike is of course suitable for the food industry, the materials used meet the requirements of this sector.
Do you use big bags with discharge spouts? For this we have the Modulo Pallet funnel version.
Product is delivered as a kit. Would you like to receive it assembled? Ask about the possibilities.
Need a suitable solution? We make tailor-made solutions! Check out our Special Build page, call or email us for more information!
About the Vidbag System
The VIDBAG is specially designed to unload big bags with seeds, fertilizer or even gravel in parts. Then the bag can be put away without leaking, no more half cut bags in the shed!
Thanks to the patented system of fins, the VIDBAG stays in position and closes the opening without leaking.
We have developed several frames that make working a lot easier. Do you have a specific issue for which there is no solution yet? Then take a look at our special construction page.
